Features
-
Highly energy efficient double arm designed to operate smoothly with wide range of nozzles and water pressure.
-
Designed for full coverage irrigation with medium to high water discharge.
-
Good performance even in windy condition.
-
Available with male 3/4″ and female & 1″ female connection.
-
Specially designed bayonet nozzles with spreaders for excellent water distribution uniformity and easy interchangeablity.
-
Extended wetted diameter even with medium to high flow nozzles for wider spacing
-
Manufactured with heavy duty plastic for high durability and corrosion resistance
-
Covered spring assembly protects it from external damage.
Performance data |
|||
|---|---|---|---|
| Nozzel (mm) | Pressure (kg/cm2) | Coverage Diameter (mtr) | Discharge Rate (LHP) |
| 6.0 x 3.8 | 1.0 | 24.0 | 1925 |
| 1.5 | 27.5 | 2350 | |
| 2.0 | 29.5 | 2725 | |
| 2.5 | 30.0 | 3050 | |
| 6.0 x 4.2 | 1.0 | 24.0 | 2050 |
| 1.5 | 28.0 | 2500 | |
| 2.0 | 30.0 | 2900 | |
| 2.5 | 30.5 | 3235 | |
| 6.5 x 4.2 | 1.0 | 25.0 | 2280 |
| 1.5 | 28.5 | 2800 | |
| 2.0 | 30.5 | 3225 | |
| 2.5 | 31.0 | 3600 | |
